CSG-GH series gearbox

abstract

The CSG-GH series standard uses mounting flanges and one press input couplings for servo motors from various companies, making it a series with simple motor installation. The CSG series is the highest specification type that increases torque capacity by 30% and gearbox lifespan by 43% from the standard CSF series.

Specialties

It is a combination type equipped with high rigidity bearings (cross roller bearings) that are suitable for servo motors of various companies and have a one click installation feature.

High torque

Long lifespan (increased rated lifespan)

No back gap

CSF series ratio: increases torque capacity by 30%

43% increase in lifespan (10000 hours)

※ Motor matching can be confirmed through selection tools

1. Model name: CSG series

2. Models: 14, 20, 32, 45, 65

3. Reduction ratio: 50, 80, 100, 120, 160

4. Type: GH=gearbox type

5. Output shaft shape:

F0=flange output

J2=straight axis (keyless)

J6=Straight axis (with key and center screw hole)

6. The shape of the motor flange and input shaft coupling shall comply with (depending on the installation of the motor)

7. Non standard products:

● Unsigned=standard product

SP=non-standard product
